ZJ-TIBO is a worldwide manufacturer and distributor of unrivalled turbine expander solutions, parts and accessories and services for a wide range of industries and applications. With over 15 years of turbine expander knowledge and expertise, you can trust ZJ-TIBO to provide you with a solution you can rely on!
Expander With Compressors Brake
Compressor loaded expanders with oil lubricated bearings. The expander and compressor wheels are mounted on a common shaft and the energy recovered from the expansion is powering the compressor wheel that can be used as a booster compressor.It meets key needs in many of industrial processes becuase of efficiency, a smaller footprint and faster installation times.
Product detail:
● Warm unit and cold unit
● Provide refrigeration for air separation,natural gas liquidation,hydrocarbon recovery, industrial tail gas recovery, ethylene cold box,and other cryogenic process.
● Gas including Air, Nitrogen, Hydrogen, Natural Gas and other Hydrocarbon Gases
● Flow rate: 4000~126500Nm3/h (up to 126500Nm3/h ASU)·
● Pressure Range: 0.2-10 MPa
● Temperature Range: -260-200°C
● Expander Efficiency: up to 93%
● Power up to 5000 kw
● Shaft Speed: 10.000-100,000 rpm/min
● Impeller Size: 60-800mm (one piece forged closed impellers)
Expander With Oil Brake
Oil brake loaded expanders designed for low pressure applications.
A modular lube oil system is feeding the oil brake and bearings.
Variable nozzles allow operating on a wide range of flows and pressures.
Product detail:
● Provide refrigeration for air separation,natural gas liquidation,hydrocarbon recovery, industrial tail gas recovery, ethylene cold box,and other cryogenic process.
● Gas including Air, Nitrogen, Hydrogen, Natural Gas and other Hydrocarbon Gases
● Flow rate: 3000~30000Nm3/h
● Pressure Range: 0.1-8 MPa
● Temperature Range: -260-200°C
● Expander Efficiency: up to 90%
● Power up to 120 kw
● Shaft Speed: 5,000-150,00 rpm/min
● Impeller Size: 60-800mm (one piece forged closed impellers)
Expander With Generator Brake
Recovering energy from gas expansion to produce electricity without burning any fuel, and therefore with no CO2 emission.
Using natural gas pressure (Pressure to Power application) or heat as a primary source of energy (Heat to Power application).
Product detail:
● Single stage and Multi stages
● Recovering and Generating Electricity from Gas Pressure Letdown, Compressed AirEnergy Storage (CAES), and other Energy Transferring Process
● Medium Gas：Air, Nitrogen, Hydrogen, Natural Gas and other Gases
● Flow rate: 4,000~800,000 Nm3/h
● Pressure Range: 0.6-14 MPa,
● Temperature Range:-100-200°C
● Expander Efficiency: up to 85%
● Power Generation:100-5000 kW
● Speed: 5,000-40,000 rpm
● Impeller Size: 80-600 mm (one piece forged closed impellers)
Cryogenic Centrifugal Pump
Widely use for liquid oxygen, liquid nitrogen, liquid argon, liquefied natural gas, cryogenic liquid loading and unloading; cryogenic liquid transportation..
Product detail:
● The structure is compact and simple.
● Rotor balancing level G2.5, more reliable operation.
● Using inducer to improve the anti-cavitation performance.
● With metal hose, reduce the impact of cryogenic stress on the unit.
● According to the working condition using mechanical seal or gas labyrinth seal.
● Optional frequency conversion motor to make the pump a wider range of operation..
● Overcurrent components using copper alloy, to ensure the safety of special conditions.
